Hydraulic Baling Press, Metal Scrap Baler (Bailer)

Why Choose Scrap Baler?

Y81 series hydraulic scrap metal baling presses are applied in steel mills, recycling plants, ferrous & non-ferrous smelting industry to compact scrap metal (steel, copper, aluminum, stainless steel, discarded automobiles, etc) into acceptable furnace charges in the shapes of cuboids, cylinders & octagons. Our group company produce and export large quantity of balers to overseas customers, and help them achieve more benefits from compacting their scraps. By using scrap metal baler, scrap yard owners can load more scraps into truck or containers, so that they can save more cost in transportation; steel mill owners can feed more scraps into their furnace with less time, so that they can reduce furnace loss and get more turn-back from melting scraps.

Our Balers’ Features:

1/ Control model：Manual valve (or PLC control)

2/ Discharging method: Turn-out discharging from press box

3/ Baler Press force：lid, side, main pressure cylinders

4/ Bale shape：cuboid; octagon

5/ Wear plate：carburizing and hardening, better anti-wearing; A3 Steel, linked with bolts, can replace each of wear plates; High pressure chamber (8 PCs)：can choose #45 steel, Mn65; Low pressure chamber：can choose #45 steel
6/ Normal spare parts：oil seals, tools; other spares：high-pressure hose；filter core；electrical elements；oil caps

Technical Parameters:

Model	Main Cylinder Force	Load Box Size (mm)	Bale Size (mm)	Bale Weight (kg)	Capacity (Ton/hr)	Power (kW)
YE81F-63	63Ton	1000×600×500	190×190	15-30	0.4-0.8	7.5
YE81F-100	100Ton	1000×600×500	200×200	15-30	0.4-0.8	11
Y81F-125A	125Ton	1100×700×550	200×200	15-35	0.4-0.8	15
Y81F-125C	125Ton	1150×700×600	250×250	30-50	0.8-1.2	15
YE81F-125D	125Ton	1200×700×600	300×300	50-70	1.0-1.5	15
Y81F-125F	125Ton	1200×900×600	300×300	50-70	1.0-1.8	15
Y81F-125H	125Ton	1400×800×700	300×300	60-90	1.5-2.0	22

Optional configuration:（Customers' choice）

A. Oil Cooler (Water Cooler, or Forced Air cooler)
B. Oil Heater (Used in cold areas)
C. Cutting blade (16-25mm), and teeth in two sides
D. "NOK" sealing for cylinder
E. Magnetic oil filter
F. Diesel engine or generator
G. Pre-feeding loading hopper
H. One-piece Structure(Easy for loading container and free of installation)
I. CE Certification(GOST Certification)
J. On-site installation supervision

More details pls contact us at HAYWOOD.CHUNG@GMAIL.COM
